4/8-Kanal universelle Schnittstelle

Mutlusan KNX Universal Interface works as an interface between conventional switches/push buttons and the KNX system. It can also be connected to any device that sends dry contact signals. There are two versions available: 4-channel and 8-channel. Each channel can be configured as either an input or an output. Each channel supports the following functions: ● Switching ● Dimming ● Shutter control ● Sending values ● Scene control ● Counter ● External LED control Mutlusan KNX Universal Interface includes 4 logic function blocks, which can be set to AND, OR, or XOR operations. In addition to these logic capabilities, it fully supports the following functions: ● Switch (ON/OFF) ● Scene ● Value It is compatible with ETS5 and higher versions. To support external LED operation, series resistors are integrated into the device. The power supply for the external LEDs is provided directly by the device.
