6119/20 2f-Universalschnittstelle, UP
6119/20
Binary Input Display Heat, 2f/1.3a
Binary Input Display Heat, 2f/1.3a
Binary Input Display Heat, 2f/1.3a
Interface with 2 channels as inputs or outputs parameterisable. Connecting cables max. 10 m. Inputs for potential free contacts. Outputs: 5 V max. 2 mA (e.g. LED) For flush-mounted sockets with a depth of 60 mm or also suitable for hollow-wall sockets. Dimensions: 39 x 40 x 12 mm
| Category | Value |
|---|---|
| Catalog Item Name | 6119/20 2f-Universalschnittstelle, UP |
| Application Program Name | Binary Input Display Heat, 2f/1.3a |
| Order Number | 6119/20 |
| Rail Mounted | No |
| Manufacturer Website | ABB AG (Busch - Jaeger) |
