Switch/Shutter Actuator 4 Channel

ITS525-0204
The Switch/Shutter Actuator is a versatile device that allows a variety of configurations. The Switch/Shutter Actuator device is intended to cover every automation requirement in a smart building for safe and efficient operations. The communication of the devices via the KNX bus enables information exchanges with KNX sensors and integration with a building management system. The Switch/Shutter Actuator has been developed to provide the whole control in the residence and hotel sectors. The usage of these devices guarantees the efficient management and provision of rooms. The manual control of the outputs is possible through the push buttons on the device. It allows the control of the outputs when bus communication failures between devices occur. The Switch/Shutter Actuator is supplied with power from the KNX and accordingly does not need any external power supply. The complete configuration of the device is performed via ETS. The type and number of the available objects depend on the settings with ETS.
Category Value
Catalog Item Name ITS525 - 0204 Switch/Shutter Actuator Secure
Application Program Name Switch/Shutter Actuator, 4 Channel/1.2
Order Number ITS525-0204
Rail Mounted Yes
Manufacturer Website Interra
Technical Documentation
