Universal dry contact Interface 4 channels VIVO

VIVO Polluce

The POLLUCE KNX 4x Pushbutton Interface can be used with regular switches or buttons or for sensing technical binary signals. The device can be placed next to a switch in a junction box (60 mm diameter, 40 mm deep). It is designed to detect any dry contacts such as conventional switches and buttons. These dry contacts are connected with four 28cm long core pairs. Contact scanning voltage is supplied by the input interface. The connection is through BUS cable permanently connected to the input interface. The cables connecting the switches/buttons to the input interface may be run for up to 10m. The commands for the available functions can be given to the actuators via the connected switches/buttons. The application program is selected via the ETS, its parameters and address are properly assigned and downloaded to the input interface.

Category	Value
Catalog Item Name	Universal dry contact Interface 4 channels VIVO
Application Program Name	Push button interface 4-gang
Order Number	VIVO Polluce
Rail Mounted	No
Manufacturer Website	VIVO

Universal dry contact Interface 4 channels VIVO
