Apartamento Multiusos 3 en 1
Apartment in Jerez de la Frontera
Applications Used
Lighting
Heating, Ventilation & Air conditioning (HVAC)
Security and Safety
Operation and Visualisation
Energy Management/Smart Metering
Other
Automation and Remote Access
Blind and Shutter Control
Project Details
| Category | Value |
|---|---|
| Project Category | Apartment |
| Project Type | Residential |
| Year of Completion | 2024 |
| Project Size | 1 – 100 |
| Number of KNX Devices Used | 1 – 25 |
| KNX Transmission Media | Twisted pair |
| Man Hours | 251 – 500 |
| Man Power | 1 – 5 |
Featured in this project
Detailed Description
Energy Efficiency
The usage of automated functions already save energy in every installation. Especially the usage of KNX has a lot of potential for further energy savings, which can contribute to a better environmental footprint. Be extending KNX to more functions and applications, energy savings of up to 60% can be realised. Thanks to the flexibility of KNX, these functions can easily be implemented in this installation
Innovation
Smart homes and buildings are always an upgrade in comparison to a conventional installation. Not only automated functions and a higher level of comfort contribute to a higher living standard, but also the possibility to be ready for coming innovations. Thanks to the usage of KNX, the door has been opened to integrate new innovative solutions, using the worldwide STANDARD for home and building control.
Applications Used
- Lighting - Switching, Dimming, Light Scenes, Timed Control, Automatic Occupancy Detection
- Heating, Ventilation & Air conditioning (HVAC) - Central & Automatic Control, Timed Operation Modes, Automatic Occupancy Detection, Individual Room Control / Zone Control, CO2 / Humidity Measuring
- Security and Safety - Smoke/Fire Detection, Faults (e.g. Leak Detection, Glass Break Detection, Window Contacts), Access Control, Intrusion Detection / Alarm Systems, Emergency Lighting, Presence Simulation
- Operation and Visualisation - Switches / Push Buttons, PC Visualisation, Web Servers, Touch Panels & Display Panels, Tablets and smart phones
- Energy Management/Smart Metering - Metering, Data Logging, Visualisation, Current Detection
- Other - Audio Control
- Automation and Remote Access - Timed Functions, Logical Functions, System Supervision, Internet Access, Remote Programming, Messaging (e.g. SMS)
- Blind and Shutter Control - Individual Control, Group & Central Control, Preset Positioning, Automatic Programs, Sun Tracing (interaction with HVAC / lighting)
Customers Description
Según se escoja entre apto. turístico, larga temporada o asistencia, la funcionalidad en el apartamento cambiará.
En modo apto. turístico cuando está vacío se desconectan algunos enchufes, A/C, ACS y cocina.
Si se abre alguna ventana apagado del aire.
En modo asistencia si llaman al timbre o telefonillo las luces parpadean y si el apartamento está ocupado pero no se detecta movimiento más de 12 horas se avisa a la propietaria.
Aviso ante consumo eléctrico de cocina si supera las 5 horas.
En modo larga temporada es el cliente quien elige las automatizaciones.
Funciones comunes: integración 3 persianas, regulación de las principales luces (salón, cocina y dormitorio), alarma antiintrusión mediante contactos en puerta y ventanas.
Escenas salir, llegada a casa.
Integración Alexa, Nuki y preparado para Sonos
Alarmas de fugas de agua y humo con avisos y parpadeo de la iluminación.
Prog. horaria de ACS y persiana dormitorio.
Aviso si puerta principal queda abierta.
Contact Information
| Company Name | Ikidom |
| Company Email | info@ikidom.com |
| Company Website | https://ikidom.com |
| Contact Name | José Ignacio Domínguez |
| Contact Function | System Integrator |
