Crown Plaza Hotel in Muscat, Oman
Hotel in Muscat
Applications Used
Lighting
Heating, Ventilation & Air conditioning (HVAC)
Security and Safety
Operation and Visualisation
Energy Management/Smart Metering
Other
Automation and Remote Access
Blind and Shutter Control
Project Details
| Category | Value |
|---|---|
| Project Category | Hotel |
| Project Type | Commercial |
| Year of Completion | 2018 |
| Project Size | 5.000+ |
| Number of KNX Devices Used | 501 – 1.000 |
| KNX Transmission Media | Twisted pair |
| Man Hours | 101 – 250 |
| Man Power | 6 – 10 |
Featured in this project
Detailed Description
Energy Efficiency
The usage of automated functions already save energy in every installation. Especially the usage of KNX has a lot of potential for further energy savings, which can contribute to a better environmental footprint. Be extending KNX to more functions and applications, energy savings of up to 60% can be realised. Thanks to the flexibility of KNX, these functions can easily be implemented in this installation
Innovation
Smart homes and buildings are always an upgrade in comparison to a conventional installation. Not only automated functions and a higher level of comfort contribute to a higher living standard, but also the possibility to be ready for coming innovations. Thanks to the usage of KNX, the door has been opened to integrate new innovative solutions, using the worldwide STANDARD for home and building control.
Applications Used
- Lighting - Switching, Dimming, Light Scenes, Timed Control, Automatic Occupancy Detection, Constant Light Control
- Heating, Ventilation & Air conditioning (HVAC)
- Security and Safety
- Operation and Visualisation - Switches / Push Buttons, PC Visualisation, Web Servers, Touch Panels & Display Panels
- Energy Management/Smart Metering - Visualisation
- Other
- Automation and Remote Access - Timed Functions
- Blind and Shutter Control
Customers Description
The building is consists of total 12 floors, including 3 basements. Lighting control is covered for parking, entrance lobby, lifts, stairs, washrooms, common areas, pre-function area, meeting rooms, restaurants, spa and ballroom. Complete KNX system is implemented with lighting, 1-10V and phase dimming. All the common areas corridors, parking, stairs, washroom and lift lobbies are with motion detectors. For common areas, scenes are activated using central monitoring software, which will trigger as per the preset timing in the morning and evening. Ballrooms, specialty restaurants and spa area working with keypads and touch screens with scene setting. External landscape and façade controlled using photocell. A central monitoring station is located in the control room for full monitoring and controlling the entire system. The system is interfaced with BMS using BACnet IP, Fire Alarm using NO/NC contacts and Audio video using RS232 gateway.
