Malenovice
Family house in Malenovice, 739 11
Applications Used
Lighting
Heating, Ventilation & Air conditioning (HVAC)
Security and Safety
Operation and Visualisation
Energy Management/Smart Metering
Other
Automation and Remote Access
Blind and Shutter Control
Project Details
| Category | Value |
|---|---|
| Project Category | Family house |
| Project Type | Residential |
| Year of Completion | 2017 |
| Project Size | 501 – 1.000 |
| Number of KNX Devices Used | 101 – 300 |
| KNX Transmission Media | Twisted pair |
| Man Hours | 1.001 – 2.000 |
| Man Power | 1 – 5 |
Featured in this project
Detailed Description
Energy Efficiency
The usage of automated functions already save energy in every installation. Especially the usage of KNX has a lot of potential for further energy savings, which can contribute to a better environmental footprint. Be extending KNX to more functions and applications, energy savings of up to 60% can be realised. Thanks to the flexibility of KNX, these functions can easily be implemented in this installation
Innovation
Smart homes and buildings are always an upgrade in comparison to a conventional installation. Not only automated functions and a higher level of comfort contribute to a higher living standard, but also the possibility to be ready for coming innovations. Thanks to the usage of KNX, the door has been opened to integrate new innovative solutions, using the worldwide STANDARD for home and building control.
Applications Used
- Lighting - Switching, Dimming, Light Scenes, Timed Control, Automatic Occupancy Detection, Constant Light Control, Lighting Colour Control
- Heating, Ventilation & Air conditioning (HVAC) - Central & Automatic Control, Timed Operation Modes, Automatic Occupancy Detection, Weather Dependent Control, Individual Room Control / Zone Control, Valve Drive Control / Fan Coil Control, CO2 / Humidity Measuring, Natural Ventilation, Floor Heating Control, Boiler and burner Control
- Security and Safety - Smoke/Fire Detection, Faults (e.g. Leak Detection, Glass Break Detection, Window Contacts), Access Control, Intrusion Detection / Alarm Systems, Emergency Lighting
- Operation and Visualisation - Switches / Push Buttons, PC Visualisation, Web Servers, Tablets and smart phones
- Energy Management/Smart Metering - Metering, Data Logging, Visualisation, Current Detection, Fuel or Water tank level control
- Other - Intercom, Audio Control, Video Control
- Automation and Remote Access - Logical Functions, System Supervision, Internet Access, Remote Programming
- Blind and Shutter Control - Individual Control, Group & Central Control, Automatic Programs, Wind and Rain Protection
Customers Description
The KNX system brought great variability in the possibility of combining different technologies, which are combined into one logical unit. The customer wanted to combine all technologies into one logical unit, the KNX system was a good choice. Family house, where switched lighting is controlled, dimmed (DALI, voltage, DMX, 0-10V), window blinds, electric windows, VELUX blinds, ModBus RTU air conditioning pool, pool water technology control, sauna control, atrium air conditioning 0-10V house, floor heating, radiators, electric ladders, MaR source control, circulation pumps, DHW, pressure monitoring, main water shut-off, ventilation, access and arrival, gate, gate, electric locks, switched sockets, magnetic contacts, motion sensors, gas detector , fire sensor RS232 burglar alarm, power consumption, weather station and irrigation control, 1-wire, audio zones, projector and screen, MIELE communication hood, transfer sump, dew point, cameras, flood sensors and other.
Contact Information
| Company Name | IQ Budovy s.r.o. |
| Company Email | info@iqbudovy.cz |
| Company Website | https://www.iqbudovy.cz/ |
| Contact Name | Křůpala Radim |
| Contact Function | System Integrator |
